Hose reel cart OSM310
| Article Number | Medium | Material hose reel | Workpressure (bar) | Connection (mm) |
| ES310100 | Cold water | Steel painted | 20 | Excl. slang |
| ES310101 | Cold water | Steel painted | 12 | 12,7 |
| ES310102 | Compressed air | Steel painted | 17 | 10 |
| ES310103 | Compressed air | Steel painted | 17 | 12,5 |
| ES310104 | Hot water | Steel painted | 20 | 13 |
| ES310200 | High pressure | Steel painted | 100 | Excl. slang |
| ES310202 | High pressure | Steel painted | 100 | 10 |
| ES310300 | High pressure | Steel painted | 200 | Excl. slang |
| ES310301 | High pressure | Steel painted | 200 | 8 |
| ES310400 | High pressure | Steel painted | 400 | Excl. slang |
| ES310401 | High pressure | Steel painted | 400 | 8 |
| ES310500 | Grease | Steel painted | 600 | Excl. slang |
| ES310501 | Grease | Steel painted | 600 | 6,4 |
| ES310502 | Grease | Steel painted | 600 | 6,4 |
| ES310900 | Oil | Steel painted | 150 | Excl. slang |
| ES310901 | Oil | Steel painted | 150 | 10 |
| ES310902 | Oil | Steel painted | 150 | 10 |
| ES314100 | Cold water | SS 304 | 20 | Excl. slang |
| ES314101 | Cold water | SS 304 | 12 | 12,7 |
| ES314102 | Perslucht | SS 304 | 17 | 10 |
| ES314103 | Perslucht | SS 304 | 17 | 12,5 |
| ES314104 | Hot water | SS 304 | 20 | 13 |
| ES314200 | High pressure | SS 304 | 100 | Excl. slang |
| ES314202 | High pressure | SS 304 | 100 | 10 |
| ES314300 | High pressure | SS 304 | 200 | Excl. slang |
| ES314301 | High pressure | SS 304 | 200 | 8 |
| ES314400 | High pressure | SS 304 | 400 | Excl. slang |
| ES314401 | High pressure | SS 304 | 400 | 8 |
| ES314500 | Grease | SS 304 | 600 | Excl. slang |
| ES314501 | Grease | SS 304 | 600 | 6,4 |
| ES314901 | Oil | SS 304 | 150 | 10 |
| ES314902 | Oil | SS 304 | 150 | 10 |
Spring-rewind mechanism
– Latching system
– Fixed or swiveling mounting bracket
– Adjustable arms with roller guide
– Mountable in any position
– Max. 18m hose with max. diameter of 12.5 mm
Extra specifications:
– Spring-rewind mechanism
– Latching systems
– Fixed or swiveling mounting bracket
– Adjustable arms with roller guide
– Mountable in any position
– Max. 18m hose with max. diameter of 12.5 mm
Additional information
| Brand | OSM |
|---|---|
| Reel Material | Stainless steel |
| Swivel Material | Steel |
| Country of Origin | Germany |
| HS Code (Intrastat) | 73269098 |
